About Robotic Parts:
Robotic Parts are engineered with high precision to ensure optimal performance in automation systems. These parts, such as gears, joints, and actuators, are designed to meet tight tolerances and deliver reliable operation in industrial, medical, and consumer robotics.
Material
Made from high-quality materials like aluminum, stainless steel, and advanced polymers, robotic components offer exceptional strength, wear resistance, and longevity. These materials ensure durability even in demanding environments, such as high-temperature or high-load applications.
Customization and Versatility
Robotic Parts can be customized to fit specific robotic designs and functions. Whether it's a custom-sized gear, a specialized sensor mount, or a unique end-effector, these parts are tailored to enhance the versatility and efficiency of robotic systems.
Applications and Innovation
Robotic Parts are used in a wide range of industries, including manufacturing, healthcare, agriculture, and logistics. They enable innovations such as collaborative robots (cobots), autonomous vehicles, and precision surgical tools, driving the future of automation and smart technology.
Robotic Parts are engineered with high precision to ensure optimal performance in automation systems. These parts, such as gears, joints, and actuators, are designed to meet tight tolerances and deliver reliable operation in industrial, medical, and consumer robotics.
Material
Made from high-quality materials like aluminum, stainless steel, and advanced polymers, robotic components offer exceptional strength, wear resistance, and longevity. These materials ensure durability even in demanding environments, such as high-temperature or high-load applications.
Customization and Versatility
Robotic Parts can be customized to fit specific robotic designs and functions. Whether it's a custom-sized gear, a specialized sensor mount, or a unique end-effector, these parts are tailored to enhance the versatility and efficiency of robotic systems.
Applications and Innovation
Robotic Parts are used in a wide range of industries, including manufacturing, healthcare, agriculture, and logistics. They enable innovations such as collaborative robots (cobots), autonomous vehicles, and precision surgical tools, driving the future of automation and smart technology.
5.0
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
High-precision stainless steel CNC parts
Stainless steel precision machining parts designed for medical, food and marine engineering support rapid prototyping and mass production of complex structural parts. Using 5-axis linkage CNC center and Swiss precision lathe, it achieves the ultimate processing capability of minimum hole diameter 0.2mm and wall thickness 0.3mm, and provides 18 surface treatment solutions such as passivation, electrolytic polishing, PVD coating, etc., meeting the stringent standards of FDA, ASTM and NACE.
ISO 9001/AS9100 certified | ±0.01mm tolerance | Fully compatible with 304/316/17-4PH materials
Product Details
Processing range
Maximum size: 800×500×400mm (expandable to 1500mm)
Tolerance grade
±0.05mm for conventional parts, ±0.01mm for precision parts (ISO 2768-f)
Surface roughness
Ra 0.4μm (mirror polishing), Ra 1.6μm (fine milling), Ra 3.2μm (rough machining)
Post-processing process
Electrolytic polishing (Ra≤0.1μm), chemical passivation, titanium nitride coating, laser etching
Product Advantages
Technical advantages
Ultra-precision machining
5-axis CNC synchronous accuracy ±0.005mm
Ultimate machining capabilities
Micro-hole drilling (aperture 0.2mm±0.005mm), deep cavity milling (depth 250mm)
Multi-process integrated machining
Multiple complex processes such as milling, drilling, tapping, boring, etc. can be completed in one clamping, reducing clamping errors and improving machining accuracy and production efficiency
Material advantages
304 stainless steel
General purpose corrosion resistance, suitable for food and medical applications
316L stainless steel
Chloride corrosion resistance (ASTM A240 standard)
17-4PH stainless steel
Precipitation hardening, tensile strength ≥1310MPa
Service Advantages
Customized service
Professional engineering team can provide one-stop customized solutions from design to production according to customers' special needs.
After-sales service
Provide 24-hour online technical support, respond to customer questions in a timely manner, and regularly visit customers to ensure customer satisfaction
Global logistics
DHL/UPS dedicated line, including export customs declaration documents
Application
High-end manufacturing
Semiconductor wafer fixtures, vacuum chamber components
Marine engineering
Desalination pump impellers, subsea valve components, anti-corrosion brackets
Consumer electronics
Reactor stirring paddles, oil and gas pipeline flanges
Industrial automation
Robot joint arm, linear module slider, visual inspection bracket (anodized insulation treatment)
FAQ
If you have any questions, please feel free to contact us at ada@honscn.com or by phone at +86 17722440307
1
What formats are required for design files?
Accept STEP/IGES/SolidWorks formats, and key tolerances and surface treatment requirements must be marked
2
How to avoid hardening of stainless steel parts?
Use low-speed high-feed cutting + special coolant, and control the surface hardness to HRC≤32
3
What are the specific standards for medical-grade polishing?
Meet ASTM B912 electrolytic polishing, Ra≤0.1μm, and reduce the microbial attachment rate by 90%
4
Can magnetic stainless steel be processed?
Provide 304/316 austenitic stainless steel (non-magnetic), or 430F martensitic stainless steel (magnetic)
5
Which material is suitable for extreme high-pressure environments?
17-4PH stainless steel (H1150 state) pressure resistance ≥1000MPa
