High-precision plastic CNC parts | Multi-engineering plastic adaptation | Rapid prototyping + mass production

Material Selection​

Supports a wide range of plastic materials to meet the needs of different application scenarios:​

• General plastics: ABS (high toughness, easy processing), acrylic (good light transmittance, smooth surface), PVC (chemical corrosion resistance), PP (food grade, acid and alkali resistance), PE (low cost, impact resistance)​
• Engineering plastics: POM (polyoxymethylene, high hardness, low friction), nylon (wear resistance, self-lubricating), PETG (high transparency, impact resistance), PC (polycarbonate, high strength, flame retardant)​
• High-performance plastics: PEEK (high temperature resistance 260℃+, high strength), PSU (polysulfone, hydrolysis resistance, high insulation), PVDF (strong acid and alkali resistance, anti-aging)​

Machining Precision & Dimensions​

• Standard tolerance: ±0.05mm, meeting the needs of most industrial applications​
• Processing size range: minimum part size 1mm³, maximum processing size up to 500mm (length) × 400mm (width) × 300mm (height)

Surface Finishing

• Basic treatment: deburring, cleaning, ensuring the surface is clean
• Appearance optimization: polishing (mirror Ra 0.2μm), sandblasting (matte texture), silk screen (pattern/logo printing)
• Function enhancement: electroplating (conductive treatment), nano coating (waterproof, wear-resistant), UV spraying (anti-aging)

Complex geometry molding: through 3-axis, 4-axis or 5-axis CNC machining, complex curved surfaces, thin-walled structures (minimum wall thickness 0.5mm), deep cavities, precision threads (M1.0+) and other geometric shapes can be precisely processed

Rapid prototyping: no mold is required, CAD design is directly converted into physical parts, shortening the product development cycle, 72 The first sample can be delivered within hours

Batch consistency production: The automated processing process ensures that the dimensions of mass-produced parts are highly uniform, and the tolerance fluctuation between batches is less than 0.005mm

Material performance customization: Select plastic materials with specific properties according to application requirements, such as insulation, flame retardant, food grade, anti-static, etc.
